Description:

For those seeking the power and efficiency of a premium commercial mower without breaking the bank, the Radius X-Series is the ideal choice. This model blends the advanced features of our top-tier machines with exceptional value. Available with either a 52-inch or 60-inch UltraCut Series 4 cutting deck, the Radius X-Series is powered by robust Kawasaki commercial engines—the FX801 for the 52-inch deck and the FX921 for the 60-inch deck. Its integrated Hydro-Gear transmissions and aggressive 24-inch Kenda drive tires deliver superior traction and control, reaching forward speeds of up to 10 mph. The mower is designed for durability and low maintenance with large semi-pneumatic caster tires, cast steel caster forks, and tapered caster pivot bearings. Comfort is also a priority, with an adjustable full-suspension operator seat and an isolated floor pan. For those requiring even greater power and larger cutting capacities, the Lazer Z line offers cutting-edge productivity with decks up to 144 inches wide.

Specification:

UPC: 193308225210

Starter: Electric

Steering Control: Hydraulically dampened twin levers, adjustable fore and aft with 2-position height adjustment

Front Caster Tires: 13 x 6.5-6, smooth tread, pneumatic with sealed taper roller bearings

Drive Tires: 24 x 12-12 K3012

Parking Brake: Lever-actuated pawl brake

Tractor Frame: Unibody, welded, heavy-duty 2" x 3" rectangular tubular steel

Blade Spindles: No maintenance, sealed and non-greasable; 7.75"-diameter cutter housing with 25mm (0.98") spindle shaft and splined blade driver

Electrical: 12-volt battery with 15-amp alternator

Standard Features: Engine hour meter, cup holder, tow hitch, and jack receiver

Seat: Deluxe suspension with adjustable spring suspension, high back, molded foam, flip-up armrests, and integral safety switch

Transmission Speeds: Infinitely variable

Engine Brand: Kawasaki

Engine Model: FX921V

Engine Displacement: 999 cc

Engine Series: V-Twin

Fuel System: Carbureted

Speed: Infinitely variable from 0–10.0 mph (16.1 km/h) forward, 0–6.0 mph (9.7 km/h) reverse

Drive: Hydro-Drive

Engine Spec: FX921V_S04-R

Engine Speed: 3,820 rpm

Air Filter: Heavy-duty canister air filtration system

Fuel Capacity: 7 gallons (26.5 L) single fuel tank with single fill location

Drive Description: Dual Hydro-Gear ZT3400 hydrostatic transmission with charge pumps, relief valves, and independent, replaceable filters

Fuel Type: Gas, carbureted

PTO Engagement: MagStop electromagnetic 225-ft-lb clutch

Drive Wheel Release: Allows unit movement without engine running

Fuel Indicator: Translucent visual

Deck Lift: Foot-controlled deck lift for changing cutting height, maneuvering around obstacles, or placing in transport position

Carb Compliant: No

Safety Package: Operator Presence Controls (OPC) and drive system interlock with safety interlock system indicators

ROPS: 2-post foldable ROPS standard with seat belt and latch

Deck Style: Floating Deck

Deck Style Description: Full-floating UltraCut Series 4; side discharge standard, with molded discharge chute and options to bag or mulch

Width / Cutting Deck: 60"

Deck Construction: 10-gauge high-strength alloy top, formed and continuously seam welded, with 7-gauge side skirt

Cutting Heights: 1.5" (3.8 cm) to 5.0" (12.7 cm) in 0.25" (0.6 cm) increments, adjustable from operator's seat

Blade Tip Speed: Approximately 18,500 fpm

Blades: 3 blades at 20.50" length

Width: 72.3 in (183.6 cm)

Height: 70 in (178 cm)

Length: 80.5 in (204.5 cm)

Curb Weight: 1006 lbs

Width	Weight	Height	Length
72.3 Inch	1006 Pounds	70 Inch	80.5 Inch
