Description:

For professional landscapers seeking commercial-grade quality and innovative features at a great value, the Lazer Z E-Series zero-turn mower is the perfect choice. This model features the same robust, welded 1.5" x 3" tubular steel unibody frame found in our premium Lazer Z models, ensuring durability and reliability. The Lazer Z E-Series is available with your choice of two rugged Kawasaki® V-Twin engines, a Kohler® Command™ Pro, or a Vanguard V-Twin engine, paired with a full-floating UltraCut™ Series 4 cutting deck in widths of 48, 52, 60, or 72 inches. It also includes a full-suspension seat designed to enhance operator comfort, reducing fatigue and boosting efficiency. Like all our zero-turn mowers, the Lazer Z E-Series delivers unmatched durability and precise maneuverability. For those looking for even more advanced features, explore the rest of the Lazer Z lineup, including the Lazer Z S-Series zero-turn mower.

Specification:

• UPC: 193308240848
• Starter: Electric
• Steering Control: Hydraulically dampened twin levers, adjustable fore and aft with three-position dampeners for customized drive responsiveness; also adjustable to two height positions
• Caster Forks: 0.50" thick caster yoke arms
• Front Caster Tires: 13 x 6.50-6, smooth-tread, semi-pneumatic
• Drive Tires: 24 x 12-12, 4 ply Super Turf®
• Parking Brake: Lever-actuated disc brake
• Tractor Frame: Unibody, welded, heavy-duty 1.5" x 3" tubular steel
• Blade Spindles: No maintenance, sealed and non-greasable; 7.75"-diameter cutter housing with 25mm (0.98") spindle shaft and splined blade driver
• Electrical: 12-volt battery with 15-amp alternator
• Standard Features: Engine hour meter and cup holder
• Seat: Deluxe, two-tone, bolstered suspension seat with Elastomeric Vibration Control material, mounted on innovative Seat Isolation System for operator isolation in all three planes of motion, fore-aft slide, and seat flip-up
• Engine Brand: Kawasaki
• Engine Model: FX801V
• Engine Displacement: 852 cc
• Engine Series: V-Twin
• Transmission: Hydrostatic
• Speed: Infinitely variable from 0–10.0 mph (16 km/h) forward, 0–6.0 mph (9.7 km/h) reverse
• Drive: Hydro-Drive
• Engine Spec: FX801V-ES19-R
• Engine Speed: 3,750 rpm
• Air Filter: Heavy-duty canister air filtration system
• Fuel Capacity: 12 gallons (45.4 L), single fuel tank with single fill location
• Drive Description: Two Exmark exclusive Parker unitized pump and wheel motor systems with integrated cooling fans, shock valve, 1.7-quart integrated reservoir, spin-on filter, and heavy-duty components; 12 cc pumps and 14.5 cubic inch motors
• Fuel Type: Gas, carbureted
• PTO Engagement: MagStop electromagnetic 200-ft-lb clutch with spot brake
• Drive Wheel Release: Allows unit movement without engine running
• Fuel Indicator: Electronic sender
• Deck Lift: Foot-controlled deck lift for changing cutting height, maneuvering around obstacles, or placing in transport position
• Carb Compliant: No
• Safety Package: Operator Presence Controls (OPC) and drive system interlock with safety interlock system indicators
• ROPS: 2-post foldable ROPS standard with seat belt and latch
• Deck Style: Floating Deck
• Deck Style Description: Full-floating UltraCut Series 4; side discharge standard with molded discharge chute and options to bag or mulch
• Width / Cutting Deck: 60"
• Deck Construction: 10-gauge top, formed and continuously seam welded; 7-gauge side skirt and spindle mounting locations for improved strength and reduced weight
• Cutting Heights: 1.0" (2.5 cm) to 5.5" (11.8 cm) in 0.25" (0.64 cm) increments, adjustable from operator’s seat
• Blade Tip Speed: Approximately 18,500 fpm
• Blades: 3 blades at 20.50" length
• Width: 72.8 in (184.9 cm)
• Height: 70.5 in (179.1 cm)
• Length: 83.1 in (211.1 cm)
• Curb Weight: 1302 lbs

Width	Weight	Height	Length
72.8 Inch	1302 Pounds	70.5 Inch	83.1 Inch
